| Place of Origin: | China |
|---|---|
| Brand Name: | Qianxun |
| Certification: | CE |
| Model Number: | SR3 |
| Minimum Order Quantity: | 1pcs |
| Price: | Negotiable |
| Packaging Details: | suitcase and carton |
| Delivery Time: | 5-10day |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 10pcs/day |
| Communication Bluetooths: | V2.1+EDR/V4.1DualMode,Class2 | Communication WIFI: | 802.11b/g/n |
|---|---|---|---|
| Communication 4G: | GSM/GPRS/EDGE/LTE/UMTS/WCDMA | Communication Internal UHF: | Transmitpower1W, Frequency |
| Communication Work Distance: | 5Km In Optimal Environment | Communication WEB UI: | To Manage The Status And Settings,upgrade Firmware, Data Download |
| Communication Tilt Survey: | Support | Communication Electric Bubble: | Enable |
| Operating Temperature: | -30℃~+65℃ | Storage Temperature: | -40℃~+80℃ |
| Water/Dust Proof: | IP67 | ||
| High Light: | IP67 GPS RTK Receiver,Tilt Survey GPS RTK Receiver,SR3 RTK GNSS Receiver |
||
Qianxun IP67 GPS RTK receiver Tilt Survey RTK GNSS Qianxun SR3 price .
Technical parameter
| Static Accuracy | |||||
| Horizon: | 2.5mm+1ppmRMS | ||||
| Vertical: | 5mm+1ppmRMS | ||||
| RTK Accuracy | |||||
| Horizon: | 8mm+1ppmRMS | ||||
| Vertical: | 15mm+1ppmRMS | ||||
| SBAS Accuracy | |||||
| Horizon: | 0.6mRMS | Horizon: | 0.3mRMS | Horizon: | 0.5mRMS |
| Code Differential Accuracy | |||||
| Horizon: | 0.4mRMS | Horizon: | 0.25mRMS | Horizon: | 0.25mRMS |
| Update rate | |||||
| Up to 100HZ | Upto50Hz | Upto50Hz | |||
| Power Supply | |||||
| Battery | Dual rechargeble batteries,7.20V/3400mh*2 | ||||
| Working time | Upto10hours | ||||
| Input | 9-28VDC, withover-voltage protection | ||||
| Data Interface | |||||
| TNC | For UHF Anternal power | ||||
| 5-pin | External radio and external power | ||||
| 7-pin | Connect to PC controller and other-external device,such as Echo Sounder | ||||
| Others | SIM slot and TF slot | ||||
| Indicator | 4 indicators,Satellites,Datalink,Bluetooths,WIFI Status. | ||||
| Communication | |||||
| Memory | Internal8G;Removable memory, support TF card | ||||
| bluetooths | V2.1+EDR/V4.1DualMode,Class2 | ||||
| WIFI | 802.11b/g/n | ||||
| 4G | GSM/GPRS/EDGE/LTE/UMTS/WCDMA | ||||
| Internal UHF | Transmitpower1W, Frequency | ||||
| Work Distance | 5Km in optimal environment | ||||
| WEB UI | To manage the status and settings,upgrade firmware, data download | ||||
| Electric Bubble | Enable | ||||
| Tilt Survey | Support | ||||
| Physical | |||||
| Dimension | 156mm*76mm | ||||
| Weight | 1.2KG with 2 batteries inside | ||||
| Environment | |||||
| Operating Temperature | -30℃~+65℃ | ||||
| Storage Temperature | -40℃~+80℃ | ||||
| Water/Dust Proof | IP67 | ||||
| Shock | Survivea2m(6.6ft) poledrop,1.2m | ||||
| Vibration | Vibration resistant | ||||
