2022 Hi-target 8 core 2.0 GHZ GPS Land Surveying Equipment Hi-target V10 pro RTK Gnss Receiver price

Basic Information
Place of Origin: China
Brand Name: Hi Target
Certification: CE
Model Number: V10 pro
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: suitcase and carton
Delivery Time: 5-10day
Payment Terms: T/T, Western Union
Supply Ability: 10pcs/day
Detail Information
Channels: 800 Channels BDS:: B1, B2, B3
GPS:: L1, L2, L5 GLONASS:: L1, L2
Output Format: ASCII: NMEA-0183, Binary Code Positioning Output Frequency: 1Hz~20Hz
Static Data Format: GNS, Rinex Dual Format Static Data Difference Format: CMR, RTCM2.X, RTCM3.0, RTCM3.2
Network Mode: VRS, FKP, MAC; Support NTRIP Protocol Operating SyLinux Operating System: Android 10
Data Storage: Built-in 8GB ROM, Supports Automatic Storage Of Static Data RTK Positioning Accuracy Plane:: ±(8+1×10-6D) Mm (D Is The Distance Between The Measured Points)
RTK Positioning Accuracy Elevation:: ±(15+1×10-6D) Mm (D Is The Distance Between The Measured Points)
High Light:

8 core RTK GNSS Receiver

,

2.0 GHZ RTK GNSS Receiver

,

Land Surveying Equipment gps gnss receiver


Product Description

Product Description

2022 Hi-target 8 core  2.0 GHZ GPS Land Surveying Equipment Hi-target V10 pro RTK Gnss Receiver price .

2022 Hi-target 8 core 2.0 GHZ GPS Land Surveying Equipment Hi-target V10 pro RTK Gnss Receiver price 02022 Hi-target 8 core 2.0 GHZ GPS Land Surveying Equipment Hi-target V10 pro RTK Gnss Receiver price 12022 Hi-target 8 core 2.0 GHZ GPS Land Surveying Equipment Hi-target V10 pro RTK Gnss Receiver price 22022 Hi-target 8 core 2.0 GHZ GPS Land Surveying Equipment Hi-target V10 pro RTK Gnss Receiver price 3











Specification
















GNSS
configuration
System kernel
Using multi-star system core
Number of channels
800

BDS
B1,B2,B3
GPS
L1,L2,L5
GLONASS
L1,L2
GALILEO
E1,E5a,E5b
SBAS
yes
Output format
ASCII: NMEA-0183, binary code
Positioning output frequency
1Hz~20Hz
Differential support
CMR,RTCM2.X,RTCM3.0,RTCM3.2
Static format support
GNS, Rinex dual format static data

RTK positioning accuracy
Plane: ±(8+1×10-6D) mm
(D is the distance between the measured points)
Elevation: ±(15+1×10-6D) mm
(D is the distance between the measured points)

Static positioning accuracy
Plane: ±(2.5+0.5×10¯6D) mm
(D is the distance between the measured points)
Elevation: ±(5+0.5×10¯6D) mm
(D is the distance between the measured points)
DGPS positioning accuracy
Plane accuracy: ±0.25m+1ppm;
Elevation accuracy: ±0.50m+1ppm
SBAS positioning accuracy
0.5m
Initialization time
<10 seconds
Initialization reliability
>99.99%





Built-in communication
network
Built-in 4G full Netcom network communication
WiFi
802.11b/g access point and client mode, can provide WiFi hotspot service
Bluetooth
Built-in Bluetooth
Built-in transceiver
Power
1W/2W/5W adjustable
frequency band:
403MHz-473MHz
Transmission rate
19.2kbps/9.6kbps adjustable
Number of channels: 116 frequency bands adjustable


External radio
Power
:5W/10W/20W/30W adjustable
frequency band:
403MHz~473MHz
Transmission rate
19.2kbps/9.6kbps adjustable Number of channels: 116 frequency bands adjustable

User Interface
panel
Single button
Indicator light
Satellite lights, signal lights, power lights
Display screen
Industrial-grade OLED HD color display, capacitive touch screen


Advanced application
iPOWER smart balance technology, LBS, NFC
Smart service
Voice broadcast, voice guidance, function self-check,
DIY voice
Remote Service
Remote upgrade, remote registration, remote data download





Electrical physical properties

battery
High capacity lithium battery 6800mAh/piece (Standard 2 pieces) with power display light, removable Single battery network mobile station continuously working for
more than 10 hours
Input voltage
DC 6~28VDC, with over-discharge protection
size
Φ158mm×98mm
weight
≤1.2kg (including battery)
Power consumption
4.2W
material
Shell is made of magnesium alloy material

Environmental characteristics
Dust and water release
P67, can resist temporary immersion under 2 meters water, completely prevent dust from entering
Anti-fall
Resistance to natural drop of 3 meters
Operating temperature
-40℃~75℃
Operating hand thin






System Configuration
model
iHand5.5
operating system
Android 10
processor
CPU: 8 core; 2.0 GHZ
storage
2 GB RAM+16 GB ROM; T-Flash memory card, up to 128GB
display
5.5’’, bright Outdoor Color capaci�ve touch screen (with touch pen, can be operated with gloves)
enter
Physical full keyboard



Communication configuration
Cellular mobile
Built-in 4G full Netcom, dual card dual standby
WiFi
802.11b/g access point and client mode, can provide WiFi hotspot service
Bluetooth
Built-in Bluetooth
NFC
Support NFC IGRS
USB
USB, TypeC interface, OTG
Power performance
Built-in battery
7500 mAh internal
Working time
14 hours
Physical properties
size
236 mm*85 mm*25 mm
Weight
480g
Operating temperature
-20℃ ~ +60℃
