Product Description:
Highlights
The i76 Palm Visual RTK is a lightweight receiver that combines GNSS, IMU, and dual cameras . Weighing just 450g and rated IP68 , it maintains a 96% fixed rate even in areas with high solar activity. Its CAD AR visual stakeout enables precise path planning, while the 5th Gen Ultra-IMU ensures accuracy even at a 60° tilt .
With over 17 hours of battery life , the i76 offers precision and adaptability for professionals seeking precision and adaptability .
Features:
Increase overall stakeout efficiency by 40% with CAD AR visual stakeout. This technology integrates base maps with augmented reality (AR) for precise path planning and real-time visualization.
Achieve superior accuracy with the 4th generation air-medium GNSS antenna and iStar 2.0 technology. The i76 delivers over 96% reliable fixed RTK rate in high solar activity regions, ensuring reliable data.
Enhance measurement precision by 30% with the 5th Gen Ultra-IMU. It offers automatic pole tilt compensation up to 60°, ensuring accuracy within 3 cm without manual initialization.
The i76 integrates GNSS, IMU, and dual wide-angle cameras, providing a seamless surveying experience. The system supports real-time stakeout and measurement with intuitive visual feedback.
Enjoy easy handling and portability with the palm-sized i76, weighing just 450g. Its compact design makes it 40% lighter and 50% smaller than industry standards, enhancing field operations.
Withstand harsh environments with the i76’s IP68 rating and 2-meter drop resistance. The biomimetic structure and sapphire lens ensure durability, making it ideal for tough field conditions.
Technical Parameters:
| GPS |
L1 C/A, L1C, L1P(Y), L2P(Y), L2C, L5 |
| QZSS |
L1 C/A, L1C, L2C, L5 |
| Battery |
Li-ion 11,600 MAh, 3.7 V |
| IRNSS (NavIC) |
SPS-L5 |
| Internal Radio (Optional) |
405–470 MHz UHF Or FH915 Spread Spectrum |
| SBAS |
WAAS/EGNOS/MSAS |
| GLONASS |
L1 C/A, L1P, L2C/A, L2P, L3C |
| Galileo |
E1, E5a, E5b, E5 Alt-BOC |
| Precision Static |
H: 3 Mm + 0.1 Ppm | V: 3.5 Mm + 0.4 Ppm |
| Code Differential GNSS |
H: <0.25 M | V: <0.50 M |
Applications:
The CHCNAV i76 RTK GNSS Receiver is a versatile and high-precision positioning device designed for various applications across different industries. With its advanced features and reliable performance, this product is suitable for a wide range of occasions and scenarios.
One key application scenario for the CHCNAV i76 RTK GNSS Receiver is in land surveying and mapping. Equipped with a powerful IMU GPS system and 1408 channels, this receiver can provide accurate and real-time positioning data, making it ideal for tasks such as boundary marking, topographic mapping, and construction site surveys.
Another important use case for this product is in precision agriculture. Farmers and agronomists can benefit from the high accuracy of the CHCNAV i76 for tasks such as field mapping, crop monitoring, and yield analysis. The L-band capability of the receiver ensures reliable signal reception even in challenging environments.
Infrastructure and utility companies can also leverage the capabilities of the CHCNAV i76 RTK GNSS Receiver for asset management, infrastructure planning, and maintenance activities. The device's Advanced RTK Engine and multi-constellation support (GPS, GLONASS, QZSS) ensure precise positioning even in urban canyons or areas with limited satellite visibility.
Furthermore, the CHCNAV i76 is well-suited for construction and engineering projects that require high levels of accuracy and efficiency. Its rugged design, CE certification, and compatibility with external power supplies ranging from 9.0 to 27.0 V DC make it a reliable tool for site layout, grade control, and machine guidance applications.
With a minimum order quantity of 1 and a price of 1480 USD, the CHCNAV i76 RTK GNSS Receiver offers a cost-effective solution for professionals seeking reliable positioning technology. Payment terms of 100% T/T ensure a secure transaction process for customers worldwide.
