Total Station Angle Measurement System Repair Service Encoder Compensator Optical Plummet Calibration

Basic Information

Place of Origin:	Guangdong, China
Brand Name:	GeoMaster
Certification:	ISO 9001:2015, ISO 17123-3 Compliant
Model Number:	ANG-REP-002

Minimum Order Quantity:	1 Unit
Price:	USD 120-700 / Unit
Packaging Details:	Shock-proof foam insert in export-grade double-wall corrugated carton
Delivery Time:	5-10 working days for standard repair
Payment Terms:	T/T, PayPal, Western Union
Supply Ability:	200 Units per Month

Get Best Price Contact Now

Detail Information

Service Type:	Angle Measurement System Repair	Supported Brands:	Leica, Trimble, Topcon, Sokkia, Nikon, Pentax
Angle Accuracy After Repair:	1 Arc-second (standard), 0.5 Arc-second (high-precision)	Compensator Range:	±4 Arc-minutes (working Range)
Encoder Type Supported:	Absolute, Incremental, Magnetic	Calibration Standard:	ISO 17123-3 Compliant
Repair Warranty:	12 Months	Turnaround Time:	5-10 Working Days
Highlight:	Angle Encoder Repair , Compensator Calibration Service , Optical Plummet Alignment

Product Description

Total Station Angle Measurement System Repair & Calibration Service

Angle measurement is the foundation of total station accuracy. When encoders drift, compensators malfunction, or optical plummets go out of alignment, your survey data becomes unreliable. Our angle measurement system repair service addresses the complete angle measurement chain — horizontal and vertical encoders, tilt compensators, and optical plummet alignment — restoring your instrument to factory angular accuracy specifications. We service all major brands including Leica, Trimble, Topcon, Sokkia, and Nikon.

Key Features

Absolute & Incremental Encoder Repair — Glass disc cleaning, readhead alignment, signal processing board repair for both absolute and incremental encoders
Compensator Overhaul — Pendulum mechanism restoration, capacitive/inductive sensor recalibration, damping system service for Leica, Trimble, and Topcon compensators
Optical Plummet Alignment — Precision reticle centering and collimation on dedicated alignment bench to within 0.5mm at 1.5m
ISO 17123-3 Verification — Full-circle angle measurement verification per ISO 17123-3 procedures, including horizontal and vertical angle uncertainty assessment
Multi-Axis Calibration — Single-face and dual-face measurements verified across full 360° rotation in 15° increments
Before/After Calibration Report — Detailed report showing angular error measurements pre- and post-repair

Why Choose Our Angle System Repair

Specialized Encoder Lab — Dedicated clean-room workstations for encoder disassembly and repair, preventing dust contamination
Factory-Grade Calibration Bench — Precision collimator array with 0.1 arc-second reference accuracy for angular calibration
12-Month Warranty — Full warranty on all angle measurement system repairs
Free Diagnostic Assessment — We diagnose the root cause before any repair work begins

Service Specifications

Parameter	Value
Service Type	Angle Measurement System Repair & Calibration
Supported Brands	Leica, Trimble, Topcon, Sokkia, Nikon, Pentax
Post-Repair Angle Accuracy	1 arc-second (standard), 0.5 arc-second (high-precision)
Compensator Working Range	±4 arc-minutes
Compensator Setting Accuracy	0.5 arc-second (post-repair)
Optical Plummet Accuracy	≤0.5mm at 1.5m height
Encoder Types Supported	Absolute, Incremental, Magnetic
Calibration Standard	ISO 17123-3 Compliant
Repair Warranty	12 Months
Turnaround Time	5-10 Working Days

Frequently Asked Questions

Q: What are signs of encoder failure?
A: Angle readings drift even when the instrument is stationary, horizontal/vertical angles jump unexpectedly, or the instrument shows encoder error codes on startup.

Q: How do I know if the compensator needs repair?
A: The instrument displays "Compensator Out of Range" persistently even on stable ground, or angle readings change when the instrument is slightly tapped.

Q: Do I need to send the tribrach for optical plummet alignment?
A: We can align the instrument's integrated optical plummet without the tribrach. However, for complete system accuracy, we recommend including the tribrach for verification.
